Literate Haskell, prepared with Pandoc

{-# LANGUAGE DeriveDataTypeable, GeneralizedNewtypeDeriving,
TupleSections, ScopedTypeVariables, TemplateHaskell #-}
import System.Environment (getArgs)
import Network.BSD(getHostName)
import Control.Distributed.Static (staticClosure)
import Control.Distributed.Process
import Control.Distributed.Process.Serializable
import Control.Distributed.Process.Closure
import Control.Distributed.Process.Node hiding (newLocalNode)
import Control.Distributed.Process.Backend.SimpleLocalnet
import Control.Concurrent hiding (newChan)
import qualified Control.Concurrent as C
import Control.Monad
import Control.Monad.State
import Control.Applicative
import Control.Monad.Trans
import Data.Binary hiding (get)
import Data.Monoid
import Data.Typeable
import Data.IORef
import qualified Data.Set as S
import qualified Data.Map as M

Cloud Haskell is not...

Cloud Haskell is not Magic

• It does not automatically parallelize anything
• It does not automatically configure an architecture
• It does not automatically mean that things don't fail
• It does not automatically reconfigure when things do fail

Cloud Haskell is not even a way to distribute computation

• It does not give you a combinator to chunk things up and recombine them
• It does not have a function named mapReduce, map, or reduce.

Cloud Haskell is a substrate for distributed computation

• It gives you a way to build many sorts of distributed computation
• It gives you ways to parallelize things
• It gives you ways to configure arbitrary architectures
• It gives you ways to manage and recover from failure

Cloud Haskell is not even Plumbing

• It is pipes and wrenches

Distributed Computation is Different

Actors, a la Carl Hewitt

• processing
• storage
• communication

Quoth Sussman and Steele

"Once we got the interpreter working correctly and had played with it for a while, writing small actors programs, we were astonished to discover that the program fragments in apply that implemented function application and actor invocation were identical!"

(The key is tail call optimization)

A Koan

Objects are a poor man's closures. Closures are a poor man's object.

Add locality and they're all actors.

Actors are good

Can express just about any sort of concurrency

Actors are bad

Can express just about any sort of concurrency

Cloud Haskell = Lambdas in the Cloud!

Pay no attention

printProcess :: String -> Process ()
printProcess s = liftIO $ putStrLn s

sumProcess :: (Int,Int) -> Process Int
sumProcess (x,y) = do
  liftIO . putStrLn $ "summing these: " ++ show (x,y)
  return $ x + y

chanProcess = do
  sendP <- expect
  sendChan sendP "message one"
  liftIO $ threadDelay 10000
  sendChan sendP "message two"
  liftIO $ threadDelay 10000
  sendChan sendP "message three"

remotable ['printProcess,'sumProcess,'chanProcess]

A Program

main = do
  -- Get some instructions
  [serverType, port] <- getArgs
  -- Set up the context
  hostName <- getHostName
  distributedContext <- initializeBackend hostName port (__remoteTable initRemoteTable)
  -- The first thing a context lets you do is create a node.
  node <- newLocalNode distributedContext
  -- The other thing a context lets you do is find what other nodes are out there.
  putStrLn "Discovering peers"
  peers <- findPeers distributedContext 2000
  putStrLn "Peers discovered"
  -- About the only thing a node lets you do is run processes on it.
  runProcess node (go serverType distributedContext peers)

Our hierarchy is Host/Port (location) --> Nodes -> Processes

Process is a Monad, and MonadIO

go :: String -> Backend -> [NodeId] -> Process ()
go "boring" dc ns = do
  liftIO $ putStrLn "IO within a process"
  return ()

This process just hangs out, to keep the node alive

go "volunteer" dc ns = do
  () <- expect
  return ()

This process tells other nodes to do stuff

go "remotePrint" dc ns = do
  let tellPrint n = spawn n $ $(mkClosure 'printProcess) "hi there!"
  mapM_ tellPrint ns
  return ()
{- printProcess s = liftIO $ putStrLn s -}

This process shouldn't compile. Bad cloud haskell! Bad!

go "remotePrintBad" dc ns = do
  let tellPrint n = spawn n $ $(mkClosure 'printProcess) (123::Int)
  -- Oh no! What happened to my static types!!!?
  mapM_ tellPrint ns
  return ()

{- printProcess s = liftIO $ putStrLn s -}

(Like sending a text message in french to an anglophone).

This process tells other nodes to compute stuff and return

go "remoteCall" dc ns = do
  let doIt n = call $(functionTDict 'sumProcess) n $
                        $(mkClosure 'sumProcess) (12::Int,25::Int)
  res <- mapM doIt ns
  liftIO $ putStrLn $ "returned: " ++ show res

{-
sumProcess :: (Int,Int) -> Process Int
sumProcess (x,y) = do
  liftIO . putStrLn $ "summing these: " ++ show (x,y)
  return $ x + y
-}

Interprocess communication is always strict (the wire enforces this).

After synchronous and asynchronus computation we have aynchronous communication

go "remoteChan" dc ns = do
  (sendP,recP) <- newChan
  let doIt n = do
        pid <- spawn n $ staticClosure $(mkStatic 'chanProcess)
        send pid sendP
  mapM_ doIt ns
  forever $ liftIO . putStrLn =<< receiveChan recP

{-
chanProcess = do
  sendP <- expect
  sendChan sendP "message one"
  liftIO $ threadDelay 10000
  sendChan sendP "message two"
  liftIO $ threadDelay 10000
  sendChan sendP "message three"
-}

Some classic concurrency primitives

MVars

newtype DMVar a = DMVar ProcessId deriving (Binary, Typeable)
newtype MVTake = MVTake ProcessId deriving (Binary, Typeable)
newtype MVPut a = MVPut (a,ProcessId) deriving (Binary, Typeable)
newtype MVResponse a = MVResponse {getMVResponse :: a} deriving (Binary, Typeable)
newtype MVSuccess = MVSuccess () deriving (Binary, Typeable)

newDMVar :: forall a. Serializable a => Process (DMVar a)
newDMVar = do
  mv <- liftIO $ (newEmptyMVar :: IO (MVar a))
  -- Note that this really is forever. No systemwide GC :-(
  p <- spawnLocal $ forever $ receiveWait
        [
         -- note the extra spawnlocal
          match $ \(MVTake pid) -> spawnLocal $
                       liftIO (takeMVar mv) >>= send pid . MVResponse
        , match $ \(MVPut (v,pid)) -> spawnLocal $
                       liftIO (putMVar mv v) >> send pid (MVSuccess ())
        ]
  return $ DMVar p

takeDMVar :: Serializable a => DMVar a -> Process a
takeDMVar (DMVar pid) = do
  spid <- getSelfPid
  send pid (MVTake spid)
  link pid
  res <- getMVResponse <$> expect
  unlink pid
  return res

putDMVar (DMVar pid) x = do
  spid <- getSelfPid
  send pid $ MVPut (x,spid)
  link pid
  MVSuccess () <- expect
  unlink pid
  return ()

The general pattern: Process wrap state, messages interact with processes.

Broadcast Channels

Note that standard Chans have only the send end serializable

newtype DChan a = DChan (SendPort a, ProcessId) deriving (Binary, Typeable)
newtype DCSubscribe = DCSubscribe ProcessId deriving (Binary, Typeable)
newtype DCDie = DCDie () deriving (Binary, Typeable)
newtype DCResponse a = DCResponse {getDCResponse :: a} deriving (Binary, Typeable)

newDChan :: forall a. Serializable a => Process (DChan a)
newDChan = do
  (sendP,recP) <- newChan
  localChan <- liftIO $ (C.newChan :: IO (C.Chan a))
  p <- spawnLocal $ getSelfPid >>= \mp -> forever . receiveWait $
       [
         match $ \(DCSubscribe pid) -> do
           newChan <- liftIO $ dupChan localChan
           spawnLocal $ do
             link pid
             link mp
             forever $ send pid . DCResponse =<< liftIO (readChan newChan)
       , match $ \(DCDie ()) -> terminate
        ]
  return $ DChan (sendP, p)

writeDChan (DChan (sp,_)) x = sendChan sp

subscribeDChanGen (DChan (_,pid)) f = do
  spid <- getSelfPid
  spawnLocal $ do
    link spid
    send pid . DCSubscribe =<< getSelfPid
    forever $ f . getDCResponse =<< expect
  return ()

subscribeDChan dc f = do
  localChan <- liftIO $ C.newChan
  subscribeDChanGen dc (liftIO . writeChan localChan)
  return $ readChan localChan

subscribeCommutativeMonoid dc f = do
  localVar <- liftIO $ newIORef mempty
  subscribeDChanGen dc (\x -> liftIO $ atomicModifyIORef localVar (\v -> (v `mappend` x,())))
  return $ readIORef localVar

Barriers (a la Communicating Sequential Processes)

--Value types
newtype DBarrier = DBarrier ProcessId deriving (Binary, Typeable)
newtype Enrolled a = Enrolled a deriving (Binary, Typeable)

-- Message types
newtype DBSync = DBSync ProcessId deriving (Binary, Typeable)
newtype DBEnroll = DBEnroll ProcessId deriving (Binary, Typeable)
newtype DBResign = DBResign ProcessId deriving (Typeable, Binary)
newtype DBClear = DBClear () deriving (Typeable, Binary)

By the way we can use strings instead of newtypes

newDBarrier = do

  enrolledSet <- liftIO $ newMVar (S.empty :: S.Set ProcessId,
                                   S.empty :: S.Set ProcessId,
                                   M.empty :: M.Map ProcessId MonitorRef)

  let resign pid = do
          mr <- liftIO . modifyMVar enrolledSet $ \(enrolled,synced,mrmap) ->
                   return ((S.delete pid enrolled,
                            S.delete pid synced,
                            M.delete pid mrmap),
                           M.lookup pid mrmap)
          maybe (return ()) unmonitor mr

  p <- spawnLocal $ forever . receiveWait $
       [
         match $ \(DBEnroll pid) -> do
           mr <- monitor pid
           liftIO . modifyMVar_ enrolledSet $ \(enrolled,synced,mrmap) ->
                  return (S.insert pid enrolled,
                          synced,
                          M.insert pid mr mrmap),
         match $ \(DBSync pid) -> do
             releaseList <- liftIO . modifyMVar enrolledSet $
               \(enrolled,synced,mrmap) ->
                      let synced' = S.insert pid synced
                      in return $
                          if enrolled == synced'
                            then ((enrolled,S.empty,mrmap),synced')
                            else ((enrolled,synced',mrmap),S.empty)
             mapM_ (`send` DBClear ()) $ S.toList releaseList,
         match $ \(DBResign pid) -> resign pid,
         match $ \(ProcessMonitorNotification mr pid dr) -> resign pid
        ]
  return $ DBarrier p

dbEnroll db@(DBarrier pid) = do
  spid <- getSelfPid
  send pid (DBEnroll spid)
  return $ Enrolled db

dbSync (Enrolled db@(DBarrier pid)) = do
  spid <- getSelfPid
  send pid $ DBSync spid
  link pid
  DBClear () <- expect
  unlink pid
  return db

Monads for consistent distributed traces

-- A Lamport Clock is a simple logical clock
-- It tracks an abstract notion of time, not wall-clock time.
-- Every clock has a time and a location (process).
newtype LamportClock = LamportClock (Integer, ProcessId)
   deriving (Eq, Ord, Binary, Typeable)

-- When a clock sees the state of another clock, it sets its time
-- to be greater than the max of the two times.
updateClock :: LamportClock -> LamportClock -> LamportClock
updateClock (LamportClock (xi, xpid)) (LamportClock (yi,_)) =
       LamportClock (max xi yi + 1, xpid)

A Lamport Monad

newtype LamProcess a = LamProcess (StateT LamportClock Process a)
    deriving (Functor, Applicative, Monad)

getClock = LamProcess get
incrClock = LamProcess . modify $ \(LamportClock (xi,xpid)) ->
                  LamportClock (xi+1,xpid)

-- Only safe for lifting single message primitives.
liftP :: Process a -> LamProcess a
liftP x = incrClock >> LamProcess (lift x)

-- IO doesn't increment clock
instance MonadIO LamProcess where
   liftIO x = LamProcess $ lift . liftIO $ x

Some lifted primitives

lsend :: Serializable a => ProcessId -> a -> LamProcess ()
lsend pid x = getClock >>= \c -> liftP $ send pid (c,x)

lexpectClocked :: forall a. Serializable a => LamProcess (LamportClock,a)
lexpectClocked = liftP expect >>= \(c,x) -> LamProcess $
                      modify (updateClock c) >> return (c,x)

lexpect :: forall a. Serializable a => LamProcess a
lexpect = snd <$> lexpectClocked

• if A before B then timestamp at A < timestamp at B
• if timestamp A > timestamp B then A did not happen before B
• same tricks work for vector clocks

What we don't have

• Logging trees (aka distributed logging) (lamports help)
• Supervision (Monitoring is halfway there)
• Out-of-process supervision (i.e. FFI code)
• Code swapping (Supervision takes you halfway there) [Out of scope]
• Core monitoring functionality / pluggable, inspectable servers.
• Interactive, interruptable, resumable computation (lisp style)
• Full sets of concurrency models -- CSP, Orc, etc.
• Classic algos -- Vector Clocks, Paxos, etc.

In conclusion:

This old gem:

punk!

• This is lambda abstraction
• This is application
• This is distribution

Now go and write some programs!
